型号 | Fig. | φD | L | φC | L1 | L2 | L3 | L4 | φC1 | φD1 | kg | 平衡值 |
BT30-DTB3-90 | 1 | 0.5~ 3.175 | 90 | 10 | 27 | 13 | 28 | 一 | 25 | 一 | 0.6 | 1.7 |
BT30-DTB7-75 | 1 ~ 7 | 75 | 21 | 53 | 一 | 一 | 一 | 0.5 | 2.4 | |||
BT30-DTB7-105 | 105 | 83 | 3.4 | |||||||||
BT30-DTB12-75 | 75 | 30 | 53 | |||||||||
BT30-DTB12-105 | 2.5~13 | 105 | 83 | 0.7 | 5.6 | |||||||
BT40-DTB3-80 | 1 | 0.5~ 3.175 | 80 | 10 | 27 | 13 | 13 | 一 | 25 | 一 | 1.3 | 2.8 |
BT40-DTB3-110 | 110 | 43 | 1.4 | 3.2 | ||||||||
BT40-DTB3-110L | 57 | 13 | 1.3 | 2.8 | ||||||||
BT40-DTB7-60 | 1 ~ 7 | 60 | 21 | 33 | 一 | 一 | 一 | 1.0 | 3.7 | |||
BT40-DTB7-105 | 105 | 78 | 1.1 | 4.8 | ||||||||
BT40-DTB7-135 | 135 | 75 | 11.8 | 21.2 | 30 | 1.3 | 5.2 | |||||
BT40-DTB7-165 | 165 | 75.5 | 35.3 | 27.2 | 40 | 1.6 | 5.4 | |||||
BT40-DTB7-195 | 195 | 57.2 | 1.9 | 5.6 | ||||||||
BT40-DTB12-90 | 2.5~13 | 90 | 30 | 63 | 一 | 一 | 一 | 1.2 | 5.3 | |||
BT40-DTB12-120 | 120 | 93 | 1.3 | 7.6 | ||||||||
BT40-DTB12-150 | 150 | 105 | 11.8 | 6.2 | 40 | 1.5 | 8.4 | |||||
BT40-DTB12-180 | 180 | 36.2 | 1.8 | 8.7 | ||||||||
BT40-DTB12-210 | 210 | 66.2 | 2.1 | 8.9 | ||||||||
BT50-DTB7-75 | 1 | 1 ~ 7 | 75 | 21 | 37 | 一 | 一 | 一 | 一 | 一 | 3.5 | 11.7 |
BT50-DTB7-105 | 105 | 67 | 3.7 | 12.3 | ||||||||
BT50-DTB7-135 | 135 | 75 | 11.8 | 10.2 | 30 | 3.8 | 18.6 | |||||
BT50-DTB7-195 | 195 | 58.8 | 23.2 | 50 | 4.6 | 25.0 | ||||||
BT50-DTB7-255 | 255 | 75.5 | 82.3 | 59.2 | 60 | 6.1 | 27.6 | |||||
BT50-DTB7-315 | 2 | 315 | 75 | 58.8 | 43.7 | 99.5 | 50 | 7.4 | 33.9 | |||
BT50-DTB12-75 | 1 | 2.5 ~13 | 75 | 30 | 37 | 一 | 一 | 一 | 一 | 一 | 3.7 | 12.5 |
BT50-DTB12-105 | 105 | 67 | 3.9 | 14.8 | ||||||||
BT50-DTB12-135 | 135 | 97 | 4.0 | 15.3 | ||||||||
BT50-DTB12-195 | 195 | 105 | 35.3 | 16.7 | 50 | 4.7 | 24.3 | |||||
BT50-DTB12-255 | 255 | 58.8 | 53.2 | 60 | 5.9 | 28.4 | ||||||
BT50-DTB12-315 | 2 | 315 | 50.2 | 63 | 7.5 | 34.1 | ||||||
A63-DTB3-75 | 3 | 0.5~ 3.175 | 75 | 10 | 27 | 13 | 4 | 一 | 25 | 一 | 0.8 | 6.9 |
A63-DTB3-105 | 105 | 34 | 0.9 | 7.5 | ||||||||
A63-DTB3-105L | 57 | 4 | 0.8 | 7.0 |
型号 | Fig. | φD | L | φC | L1 | L2 | L3 | L4 | φC1 | φD1 | kg | 平衡值 |
E25-DTB3-58 | 3 | 0.5~3.175 | 58 | 10 | 27 | 16 | 4.6 | - | 18 | - | 0.1 | 0.4 |
E32-DTB3-65 | 65 | 4.5 | 20 | 0.2 | 0.6 | |||||||
E32-DTB7-65K | 4 | 1 ~ 7 | 21 | 30 | 14.2 | 10.8 | 26 | 0.9 | ||||
E40-DTB3-70 | 3 | 0.5~ 3.175 | 70 | 10 | 27 | 13 | - | 20 | 0.3 | |||
E40-DTB7-95 | 4 | 95 | 21 | 50 | 11.8 | 13.2 | 30 | 0.4 | 1.6 | |||
E40-DTB12-110 | 2.5~13 | 110 | 30 | 90 | - | - | - | 0.5 | 2.8 | |||
E50-DTB3-75 | 3 | 0.5~ 3.175 | 75 | 10 | 27 | 16 | 1.5 | 20 | 1.7 | |||
E50-DTB7-100 | 4 | 1 ~ 7 | 100 | 21 | 50 | 11.8 | 12.2 | 30 | 0.6 | 3.2 | ||
E50-DTB12-115 | 2.5~13 | 115 | 30 | 89 | - | - | - | 0.8 | 4.2 | |||
F63-DTB3-75 | 3 | 0.5~ 3.175 | 75 | 10 | 27 | 13 | 4 | - | 25 | - | 0.8 | 2.1 |
F63-DTB3-105 | 105 | 34 | 0.9 | 2.5 | ||||||||
F63-DTB3-105L | 57 | 4 | 0.8 | 2.1 | ||||||||
F63M-DTB7-100 | 4 | 1 ~ 7 | 100 | 21 | 50 | 11.8 | 12.2 | 30 | 0.9 | 3.3 | ||
F63M-DTB12-120 | 2.5~13 | 120 | 30 | 70 | 40 | 1.1 | 4.8 | |||||
DN40AD-DTB3-80 | 1 | 0.5 ~3.175 | 80 | 10 | 27 | 13 | 8.8 | 25 | - | - | 1.2 | 3.5 |
DN40AD-DTB3-110 | 110 | 38.8 | 1.3 | 3.6 | ||||||||
DN40AD-DTB3-110L | 57 | 8.8 | 1.2 | 3.9 | ||||||||
DN40AD-DTB7-105 | 1.0 ~ 7 | 105 | 21 | 74 | - | 12.1 | - | 44.45 | 1.1 | 4.8 | ||
DN40AD-DTB7-135 | 135 | 75 | 11.8 | 17 | 30 | 1.2 | 5.0 | |||||
DN40AD-DTB12-105 | 2.5 ~ 13 | 105 | 30 | 74 | - | 12.1 | 44.45 | 1.2 | 5.7 | |||
DN40AD-DTB12-135 | 135 | 104 | 1.3 | 8.0 | ||||||||
DN50AD-DTB7-135 | 2 | 1.0 ~ 7 | 21 | 75 | 11.8 | 13.2 | 15.9 | 30 | 3.3 | 14.9 | ||
DN50AD-DTB7-195 | 195 | 58.8 | 26.2 | 50 | 4.1 | 21.5 | ||||||
DN50AD-DTB12-135 | 2.5 ~ 13 | 135 | 30 | 100 | - | - | - | 3.5 | 11.7 | |||
DN50AD-DTB12-195 | 195 | 105 | 35.3 | 19.7 | 50 | 4.2 | 20.8 | |||||
ST12-DTB3 | 5 | 0.5~ 3.175 | 29 | 10 | 25 | 61 | - | - | - | 12 | - | - |
ST16-DTB3 | 38.5 | 27 | 81.5 | 16 | ||||||||
ST20-DTB3 | 48 | 102 | 20 | |||||||||
ST25T-DTB7-15 | 6 | 1 ~ 7 | 15 | 21 | 110 | - | 25 | |||||
ST25T-DTB7-45 | 45 | |||||||||||
ST25T-DTB7-75 | 75 | |||||||||||
ST32T-DTB7-15 | 15 | 92 | 32 | |||||||||
ST32T-DTB7-45 | 45 | |||||||||||
ST32T-DTB7-75 | 75 | |||||||||||
ST32T-DTB12-15 | 2.5~13 | 15 | 30 | |||||||||
ST32T-DTB12-45 | 45 | |||||||||||
ST32T-DTB12-75 | 75 | |||||||||||
S32-DTB7-15 | 6 | 1 ~ 7 | 15 | 21 | 70 | - | - | - | - | 32 | - | - |
S32-DTB12-40 | 2.5~13 | 40 | 30 |
■选购品
● DETa-1 超弹性筒夹→ P.31 ●扳手→ P.31 ●拉钉 ( BT ) → P.77
●清洁用具→ P.31
■标准附属品
● 冷却液导管( HSKーA ) → P.119
■备考
● BT30-DTB12 型的拉钉为后拉螺拴一体型专用拉钉。
拧紧时请选用市售的单口扳手(13mm)
● E32-DTB7-65K 无法使用过盈量, 夹持径仅限筒夹的基准径。
● HSK-E 刀柄不附带冷却液导管。也无法安装冷却液导管。
